Construct a triangle \(TRY\) with \(RY = 4 \ cm\), \(TR = 7 \ cm\), \(\angle R = 140°\). Construct an altitude from \(T\) to \(RY\).
Construction:
Step 1:
Step 2:
Step 3:
Step 4:
Step 5:
Step 6:
Step 7:
Thus, \(TD\) is the altitude of the triangle \(TRY\).
Answer variants:
Keep the ruler aligned to the base. Place the set square on the ruler as shown, such that one of the edges of the right angle touches the ruler.
Slide the set square along the ruler till the vertical edge of the set square touches the vertex \(T\).
Draw the altitude to \(RY\) through \(T\) using the vertical edge of the set square.
Join \(TY\)
With \(R\) as centre and \(7 \ cm\) as radius, draw an arc which cuts the arm at \(T\).
Using protractor, construct \(\angle R = 140^{\circ}\) by drawing the other arm of the triangle.
Draw a base length \(RY = 4 \ cm\).
